This is just the control box. The tower mounted remote antenna switch is not included. The control box includes controls for the remote switch as well as a five-position built-in coax switch. Unit operates on 120 or 240 VAC power.
Unit is physically in good condition. Cabinet needs cleaning, or possibly refinishing. Unit has not been tested. Manual is available in PDF format.
This is a Heathkit course entitled: “How to Understand and Use your …Oscilloscope”. It includes a 174 page manual, a breadboard trainer test chassis and numerous miscellaneous components. You can read more here:
A few of the components are missing. These are common half-watt resistors and common capacitors that should be easy to obtain. Perhaps a bit harder, two of the transistors have a broken lead. These are old GE 4JX1C707 germanium PNP transistors; they can be replaced with the ECG-160.
New style of Heathkit LG-1 HF laboratory signal generator - 150 KHz to 30 MHz.
Item is clean but has erratic output.
This equipment as been donated to the OCARC by WA6BSV, son of AC6C.
The equipment is located in the City of Orange, CA, at the QTH of Bob, AF6C, and is available for pickup. Workout any shipping details with Bob. Sorry, no shipping to a foreign address. You are welcome to schedule a time to look over the equipment.
Contact at (714) 639-5074 if you have any questions or want to examine the equipment.
Equipment is subject to prior sale.
